Telescopic versions | 1 |
Max. reach | 6,7 m |
Lifting torque, gross | 42 kNm |
Lifting force at max. reach | 4,4 kN |
Boom extension | 1,7 m |
Gross slewing torque | 11,0 kNm |
Angle of rotation | 380° |
Working pressure | 21,5 Mpa |
Recommended flow | 40 - 80 l/min |
Weight with lowest pillar elevation | 708 kg |
Sectors | Forestry |
On road / Off road | Off road |
